Powerful Pedigree, Exuding Dynamic Style
The 368cc engine boasts an 11.8:1 compression ratio, achieving an impressive 28.5kW of power and 40Nm of torque with remarkable fuel efficiency.
The 368cc engine boasts an 11.8:1 compression ratio, achieving an impressive 28.5kW of power and 40Nm of torque with remarkable fuel efficiency.
Price : 6.500 €
Take a closer look at this Zontes 368G 368cc engine boasts an 11.8:1 compression ratio.
Technical Data
Whole vehicle
| length (mm) | 2230 |
| Width (mm) | 925 |
| Height (mm) | 1370 |
| Wheel base (mm) | 1560 |
| Loading capacity (kg) | 180 |
| Gross mass (kg) | 192 |
| Minimum ground clearance (mm) | 180(高版) 155(矮版) |
| Gasoline tank volume (L) | 17.5 |
| Seat height (mm) | 795(高版) 770(矮版) |
Suspension system
| Frame system | Steel pipe frame |
| Tire structure | Semi-slick tires |
| Front rim size | MT: 3.0×17 |
| Rear rim size | MT: 4.25×14 |
| Front tire specification | 110/70-17 |
| Rear tire specification | 150/70-14 |
| Front brake specification | Disc brake |
| Rear brake specification | Disc brake |
Power system
| The body | Aluminum alloy |
| Cylinder number | Single cylinder |
| Camshaft system | Single overhead camshaft(SOHC) |
| Bore X Stoke (mm) | 79 x 75 |
| Cooling system | Water cooling |
| Fuel | 95 and above |
| Compression ratio | 11.8 : 1 |
| Displacement(ml) | 368 |
| Fuel supply method | Intelligent electrical fuel injection |
| Electrical fuel injection system | BOSCH |
| Throttle configuration | ETC |
| Ignition system | Electronic ignition |
| Idling speed (r/min) | 1600 ± 100 |
| Maximum power (kW/rpm) | 28.5/7500 |
| Maximum torque (N.m/rpm) | 40/6000 |
| Transmission | 自动无级变速 |
| Economical consumption of fuel (L/km) | 3.5/100 |
